1. PLC (Power Line Carrier Communication) technology;
2. Utilizing broadband power line carrier communication technology, communication is achieved through existing power lines, eliminating the need for additional wiring and reducing construction costs. The communication speed is fast, with peak values at the physical layer
The rate can reach 0.507 Mbit/s; using OFDM modulation technology, it has strong anti-interference capability;
3. Supports automatic and rapid networking, completing the setup in 10 seconds, with support for up to 15 levels of relay, and a long communication distance;
4. The success rate of network connection is over 99.9% for one attempt;
5. Implement the acquisition and reporting of data such as input and output current/voltage, active power, apparent power, electric quantity, power factor, temperature, and on/off status of lights;
6. High-precision data acquisition scheme, meeting the national standards for electricity meter measurement;
7. Support controller temperature detection, and monitor the usage environment temperature in real-time;
8. It features functions such as overcurrent/overvoltage/undervoltage protection, overload protection, lighting condition and circuit detection, and default lighting;
9. Support various customizable network analysis data collection functions;
10. Load lightweight system RTOS, support data concurrency and fault tolerance, cell reselection, and inter-frequency networking;
11. Support zero-crossing detection for switching lights on and off;
12. Automatically execute cloud configuration strategies locally in case of network anomalies/no network status;
13. Support scheduled power-on/off and time control mode.
